Description

Extend the available play time of your outdoor sport court or recreational area by adding the Douglas LED light system.

QUICK SPECIFICATIONS

• Two-piece square steel pole is 17′ above ground
• Black baked-on polyester powder coat finish
• Two – 100-watt LED floodlights
• 13,500 delivered lumens per light fixture
• 5,000K light color for bright, clear light
• Industrial grade quality
• Ground sleeve sold separately
• 5-Year Limited Warranty

POLE

The solid base pole is made in the USA. It is constructed of square steel tubing with a 3/16″ wall thickness. The base pole is made of 3.5″ square steel and the top pole is 3″ square steel. The installed light height is approximately 17′ above ground. Light extension arm is constructed from 3.5″ square steel with smooth welded fixture brackets. All steel components are finished with a black, baked-on polyester powder coat finish. This strong finish adds resistance to chipping and the ultimate weather protection against the elements.


LIGHT FIXTURE

This system features two 100-watt LED floodlights that deliver a bright, clear light with 13,500 lumens per fixture. The 5000K color temperature provides optimal visibility for various activities, including basketball, tennis, and pickleball.

The high-strength aluminum housing makes this an industrial-grade quality product built to last. Better heat dissipation prolongs the life of the LEDs and enhances overall system reliability. The unit is waterproof, protecting it from rain, snow, and other elements. It is backed by a 5-year warranty.

GROUND SLEEVES & INSTALLATION

The pole can be installed direct burial or with optional 42″ long steel ground sleeves for semi-permanent installation.

WARRANTY

5-Year Limited Warranty


Additional Information
